Custom Insert Molding Service

Custom Insert Molding Service

Custom insert molding service

ceramics insert molding service

plastics insert molding service

Place of Origin:

Suzhou,Jiangsu,China

Brand Name:

FCE

Certification:

ISO9001/TS16949/QS/ISO14001

Model Number:

Insert Molding Service

Contact Us
Request A Quote
Product Details
Attribute Description Material Compatibility:
Works With Thermoplastics Like Polycarbonate (PC), Nylon, ABS, And Metals Like Aluminum, Brass, Copper.
Types Of Inserts:
Metal (brass, Steel, Aluminum), Ceramics, Plastics, And Electronic Components.
Molding Process:
Inserts Are Placed Into The Mold Before Injecting Molten Plastic, Bonding Them During Solidification.
Application:
Used In Automotive, Medical, Electronics, Consumer Goods, And Industrial Equipment.
Benefits:
Reduces Assembly Steps, Improves Product Strength And Durability, Enhances Thread Strength.
Cost Efficiency:
Eliminates Post-molding Processes Like Tapping, Resulting In Up To 10-20% Cost Savings.
Design Flexibility:
Allows For Complex Designs With Integrated Metal Or Other Inserts For Specific Functional Purposes.
Strength & Durability:
Provides Enhanced Mechanical Strength Due To The Integration Of Strong Materials Like Metal.
Thread Creation:
Metal Inserts Offer Superior Thread Strength Compared To Plastic-only Threads.
Industries Served:
Automotive, Medical Devices, Electronics, Consumer Products, And Aerospace.
Highlight:

Custom insert molding service

,

ceramics insert molding service

,

plastics insert molding service

Payment & Shipping Terms
Product Description

This is a part of many products that we make for the USA company named Intact Idea LLC. /Flair espresso, who designs , develops , manufactures and market level espresso makers and aggregated products and tools for the specialty coffee market. They have the ideas, but no dedicated designers to support the product from concept to reality, but FCE can do, whatever realizing or cost saving.

The part is called lock ring which is used on a partial of steamer tank, it is an insert molding part, that injection molded with LCP (LIQUID CRYSTAL POLYMER) resin , and put the copper insert in the plastic during injection molding process.

Why we use this kind of rare material?

  • The major application is this kind of material has high temperature resistance, when the part is burning on the flame, it can’t be easily burnt.
  • High mechanical strength, when you use this kind of material molded, the part is quite hard and strong.
  • high fluidity, so can be easily injection molding.
  • Compare to PEEK material, it is much cheaper but also can meet the functional requirements.

Application: Containers for electronic furnaces, Pump and valve etc

For the steamer product, since it is a tank to create the air pressure when burn on the flame ,the lock ring is used to hold the upper parts on the tank. As you know, the tank inner has quite high pressure, the lock ring will give the strong strength to hold the part to resist the inner pressure.

since it also requires screw to be created and plastic don’t be enough to hold the thread directly, so we use the copper with thread instead. The insert molding is a commonly used way in the injection molding area to create the thread.

since there 3x inserts on each ring, With the insert molding, it no needs separate action to apply the thread on, so it both saves the actions and the cost, at least 20% saving in the cost. Meantime, the strength can fully meet customer’s quality requirement.

Custom Insert Molding Service 0Custom Insert Molding Service 1
